SINOTRUK Howo 6X4 Concrete Mixer Truck

Sinotruk HOWO 6×4 Mixer truck

According to clients’ requirements, we can customize different loading capacity and volume.

Download the brochure now to view all product details and technical specifications (PDF, 689.7 KB).

We are always ready to face the most severe working conditions.

Thanks to its robust and durable body, HOWO truck has extraordinary performance in construction, mining and other application scenarios.

In the harsh working environment, HOWO is always ready to meet the severe test.

Overview

Unmatched Mixing Performance

Take on demanding concrete transport with speed and reliability in the heavy-duty HOWO Mixer Truck, engineered to maximize efficiency and minimize downtime. Designed with advanced technology, this mixer truck ensures stable mixing, consistent quality, and reduced material loss during long hauls. Whether you’re supplying concrete for urban construction, large-scale infrastructure, or remote job sites, the powerful HOWO Mixer Truck delivers top capacity, durability, and precision — driving your projects toward higher profitability.

Parameters

Item	Details
Overall Dimensions	9780mm × 2496mm × 3990mm (L × W × H)
Tare Weight	13,950 kg
Payload	28,000 kg
Front / Rear Overhang	1500 mm / 2880 mm
Wheelbase	4000 mm + 1400 mm
Track (Front / Rear)	2022 mm / 1830 mm
CHASSIS
Chassis Brand	SINOTRUK HOWO
Chassis Model	ZZ1257N4047W, driving type 6×4
Cab	HW76, left-hand drive, air-conditioner, one sleeper
Engine	SINOTRUK WD615.47, 371 hp (273 kW), Euro II emission; 4-stroke direct-injection diesel, 6-cyl in-line, water cooling, turbo-charging & inter-cooling, displacement 9.726 L
Transmission	HW19710, 10 forward / 2 reverse
Steering	ZF8098 (Germany), system pressure 18 MPa
Rear Axle	HC16 tandem axle, rated load 2 × 13 ton, ratio 5.73
Wheels & Tires	Rim 8.5-20; tire 12.00R20, 10 units; spare wheel carrier with one spare
Brakes	Service: Dual-circuit pneumatic; Parking: Spring energy, compressed air on rear wheels; Auxiliary: Engine exhaust brake
MIXING SYSTEM
Mixing Volume	10 m³
Water Tank Volume	440 L
Hydraulic Pump	ARK (Italy)
Motor	ARK (Italy)

If you are interested in this Howo Dump Truck welcome to leave your message! We will provide more details, quotations, catalogs, drawings, and videos for you!
